Washer(On-Premise)
WI Series [WI-181]
Washing
Extracting- Assured cleaning power combines with the durability needed for professional use. The WI Series is designed for low vibration and noise to fit into a wide range of work environments.
- Washing18kg
- Product No.
- WI-181
- Power
- AC200V 3-phase, 50/60Hz
- Load capacity
- 18kg
- External dimensions
- 1010 x 1180 x 1650 mm
- Weight
- 640kg
- Drum size
- 760 diameter x 486 length
- Drum rotation speed
-
- Washing
- 37～47rpm(5 levels)
- Dehydration
- 480～860rpm(5 levels)
- Motor capacity Drum
-
- Drum
- 3.7kW/4P
- Pipe Diameter
-
- Water inlet
- 25A
- Hot water inlet
- 25A（Option）
- Steam
- 15A
- Water exhaust
- 65A
- Solvent injection
- 2 cups of solvent
- Aid solvent injection
- Max 3 optional
Other lineup
-
WI-101
Washing : 10kg
-
WI-181
Washing : 18kg
-
WI-251
Washing : 25kg
-
WI-321
Washing : 30kg
| Product No. | WI-101 | WI-181 | WI-251 | WI-321 | |
|---|---|---|---|---|---|
| Power | AC200V 3-phase, 50/60Hz | AC200V 3-phase, 50/60Hz | AC200V 3-phase, 50/60Hz | AC200V 3-phase, 50/60Hz | |
| Load capacity | 10kg | 18kg | 25kg | 30kg | |
| External dimensions | 870 x 1205 x 1575 mm | 1010 x 1180 x 1650 mm | 1100 x 1290 x 1720 mm | 1180 x 1330 x 1790 mm | |
| Weight | 480kg | 640kg | 920kg | 1050kg | |
| Drum size | 630 diameter x 389 length | 760 diameter x 486 length | 840 diameter x 535 length | 920 diameter x 555 length | |
| Drum rotation speed | Washing | 44～52rpm(5 levels) | 37～47rpm(5 levels) | 34～44rpm(5 levels) | 32～42rpm(5 levels) |
| Dehydration | 600～800rpm(5 levels) | 480～860rpm(5 levels) | 420～820rpm(5 levels) | 400～800rpm(5 levels) | |
| Motor capacity | Drum | 2.2kW/4P | 3.7kW/4P | 5.5kW/4P | 5.5kW/4P |
| Pipe Diameter | Water inlet | 25A | 25A | 25A | 32A |
| Hot water inlet | 25A（Option） | 25A（Option） | 25A（Option） | 32A（Option） | |
| Steam | 15A | 15A | 15A | 15A | |
| Water exhaust | 65A | 65A | 100A | 100A | |
| Solvent injection | 2 cups of solvent | 2 cups of solvent | 2 cups of solvent | 2 cups of solvent | |
| Aid solvent injection | Max 3 optional | Max 3 optional | Max 3 optional | Max 3 optional | |
